Orion O2 Battery Management System - Split Configuration
In stock, ready to ship
$1,437.00
Shipping calculated at checkout.
Orion 02 Split BMS (48S, 72S, 96S)
High-voltage, split-pack battery management for modular EV, ESS, aerospace, and marine systems. Precise cell monitoring, balancing, and protection across physically separated packs—under one BMS.
- 48S / 72S / 96S
- Distributed packs
- High-voltage isolation
- CAN-enabled
What makes the Split configuration different?
Unlike the standard Orion 02 BMS (single, centralized unit), the Orion 02 Split BMS is designed to manage separate battery segments as part of a single BMS ecosystem. This unlocks smarter packaging and safer architectures when:
- Packs are physically distributed across the platform (front/rear, port/starboard, wing/boom, etc.).
- Space constraints prevent a single, large controller in one location.
- Wiring runs must be shortened to reduce mass, resistance, and EMI concerns.
- High-voltage isolation is required between sections for safety or compliance.
Harness note: The Split variant uses 24-cell tap harnesses for each 36-cell tap input on the controller.
Configurations & Chassis
48S
Ships on the 24–72 cell chassis.
72S
Ships on the 84–108 cell chassis.
96S
Ships on the 120–180 cell chassis.
Core Functions
- Cell voltage & temperature monitoring
- Active/Passive balancing
- Fault detection & diagnostics
- Charge/discharge contactor control
- CAN communication to VCU/charger
Built for demanding applications
Electric Vehicles
Modular battery architectures for cars, buses, off-road, and specialty EVs. Ideal for distributed battery systems in commercial platforms.
Energy Storage Systems
Containerized and cabinet ESS where independent racks/segments must operate as a single managed system.
Aerospace & UAV
Lightweight, distributed power with strict weight/balance and isolation requirements.
Marine & Industrial
Compartmentalized banks in vessels and industrial power systems with robust isolation & safety.
Why choose the Orion 02 Split BMS?
- Enhanced system flexibility: multiple pack topologies under one controller.
- Improved safety & redundancy: isolate sections to reduce failure propagation.
- Simplified wiring & installation: shorter HV runs, cleaner harnessing.
- Industry-leading protection: Orion 02 monitoring, balancing, and thermal management—without compromise.
What’s included
- (1) Main Controller
- (1) BMS Main I/O Harness
- (1) Cell Tap Harness Kit
- (1) CANdapter (not included with REM model)
- (1) Current Sensor Harness w/ (8) Thermistors (not included with REM model)
- (1) Current Sensor (not included with REM model)
